Navtrac API v1

Programmatic access to Navtrac's maritime intelligence: vessel registry and live positions, satellite position estimates, historical tracks and port calls, port traffic and congestion, marine weather and tides, sea routes, security incidents, and compliance screening — sanctions, safety records, flag risk, and emissions. All endpoints are versioned under https://navtrac.io/api/v1 and return JSON.

Last updated: October 25, 2026

Getting started

Create a developer account and wait for approval.
Generate an API key in the Developer Portal with the scopes you need.
Call GET /api/v1/status (free) to verify your key works.

curl "https://navtrac.io/api/v1/status" \
  -H "X-API-Key: YOUR_API_KEY"

Or import the Postman collection — it includes every endpoint below with the{{baseUrl}} and{{apiKey}} variables preconfigured:

Download Postman collection (v2.1)

Authentication

Every request must include your API key in the X-API-Key header. Keys carry scopes (vessels, ports, weather, compliance) that gate endpoint groups; reference and status endpoints work with any valid key. Keep keys secret — never embed them in client-side code.

Rate limits & credits

Each key has an hourly request limit (default 1,000/hour). Current usage is reported on every response via X-RateLimit-Limit, X-RateLimit-Remaining, and X-RateLimit-Reset; a 429 includes Retry-After.
Billable endpoints also consume credits from your account balance — each endpoint's cost is listed in its reference entry. Reference and status endpoints are free.
Check your remaining credits any time with GET /api/v1/status.

Errors

Errors return { "error": "message", "code": "ERROR_CODE" } with an appropriate HTTP status. Codes every endpoint can return:

HTTP	Code	Meaning
401	MISSING_API_KEY	No X-API-Key header was provided.
401	INVALID_API_KEY	The API key is unknown, revoked, or expired.
403	ACCOUNT_INACTIVE	The API account is suspended or deactivated.
403	INSUFFICIENT_SCOPE	The key does not include the scope required by this endpoint.
429	RATE_LIMITED	The key's hourly rate limit was exceeded. Check the Retry-After header.
402	INSUFFICIENT_CREDITS	The account has no credits left for this billable call.
500	INTERNAL_ERROR	Unexpected server error. Safe to retry with backoff.

Endpoint-specific validation and not-found codes (e.g. INVALID_MMSI, PORT_NOT_FOUND) are listed per endpoint below.

Endpoint reference

Vessels Ports Weather Compliance Security & voyage planning Reference & status

Vesselsscope: vessels

Search the vessel registry, fetch static details, live positions, voyages, historical tracks, and AI risk assessments.

GET/api/v1/vessels/search

Search vessels

Search vessels by name, call sign, MMSI, or IMO, optionally filtered by vessel type and flag. Provide 'q' (min 2 characters) or at least one of 'type'/'flag'.

Scope: vesselsCredits: 1Errors: INVALID_QUERY

Parameter	In	Type	Required	Description
q	query	string	no	Search text — vessel name, call sign, 9-digit MMSI, or 7-digit IMO. Min 2 characters.
type	query	string	no	Filter by vessel type name (substring match), e.g. 'cargo', 'tanker'.
flag	query	string	no	Filter by flag country code (exact, case-insensitive).
limit	query	integer	no	Page size, 1–100 (default 50).
offset	query	integer	no	Rows to skip for pagination (default 0).

Example request

curl "https://navtrac.io/api/v1/vessels/search?q=ever%20given" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "mmsi": "353136000",
      "imo": "9811000",
      "name": "EVER GIVEN",
      "callSign": "H3RC",
      "vesselType": 70,
      "vesselTypeName": "Cargo",
      "flag": "PA",
      "flagName": "Panama",
      "length": 400,
      "width": 59,
      "draught": 14.5,
      "deadweight": 199629,
      "grossTonnage": 219079,
      "yearBuilt": 2018,
      "lastSeen": "2026-08-03T09:12:44.000Z"
    }
  ],
  "meta": {
    "limit": 50,
    "offset": 0,
    "count": 1
  }
}

GET/api/v1/vessels/in-area

Vessels in an area

Live vessels inside a geographic area. Provide either a bounding box (north, south, east, west) or a circle (lat, lon, radius_nm — radius clamped to 1–300 nm).

Scope: vesselsCredits: 2Errors: INVALID_AREA

Parameter	In	Type	Required	Description
north	query	number	no	Bounding box north latitude.
south	query	number	no	Bounding box south latitude.
east	query	number	no	Bounding box east longitude.
west	query	number	no	Bounding box west longitude.
lat	query	number	no	Circle centre latitude (use with lon and radius_nm).
lon	query	number	no	Circle centre longitude.
radius_nm	query	number	no	Circle radius in nautical miles (1–300).
limit	query	integer	no	Max vessels returned, 1–500 (default 200).

Example request

curl "https://navtrac.io/api/v1/vessels/in-area?north=52.2&south=51.6&east=4.8&west=3.6&radius_nm=25" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "mmsi": "244660123",
      "name": "MAERSK DETROIT",
      "imo": "9356803",
      "vesselTypeName": "Cargo",
      "flag": "NL",
      "latitude": 51.951,
      "longitude": 4.083,
      "sog": 12.4,
      "cog": 271.5,
      "heading": 272,
      "destination": "NLRTM",
      "navStatus": 0
    }
  ],
  "meta": {
    "count": 1,
    "limit": 200
  }
}

POST/api/v1/vessels/positions

Bulk positions

Latest known positions for up to 100 vessels in one call. Credits scale with batch size: ceil(count / 10), minimum 1.

Scope: vesselsCredits: ceil(n/10), min 1Errors: INVALID_BODYTOO_MANY_MMSIS

Parameter	In	Type	Required	Description
mmsis	body	string[]	yes	Array of 9-digit MMSIs (max 100).

Example request

curl "https://navtrac.io/api/v1/vessels/positions" \
  -H "X-API-Key: YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -X POST -d '{"mmsis":["366999712","244660123"]}'

Example response

{
  "data": [
    {
      "mmsi": "366999712",
      "position": {
        "mmsi": "366999712",
        "latitude": 37.802,
        "longitude": -122.405,
        "sog": 0.1,
        "cog": 233,
        "heading": 234,
        "navStatus": 5,
        "timestamp": "2026-08-03T09:14:02.000Z",
        "source": "live"
      },
      "found": true
    },
    {
      "mmsi": "244660123",
      "position": null,
      "found": false
    }
  ],
  "meta": {
    "requested": 2,
    "found": 1
  }
}

GET/api/v1/vessels/:mmsi

Vessel details

Static registry details for a single vessel. Look up by 9-digit MMSI in the path, or pass a 7-digit IMO via the ?imo= query parameter (path value is ignored when the IMO matches).

Scope: vesselsCredits: 1Errors: INVALID_IDENTIFIERVESSEL_NOT_FOUND

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.
imo	query	string	no	7-digit IMO number as an alternative identifier.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "mmsi": "366999712",
    "imo": "7625354",
    "name": "GOLDEN GATE",
    "callSign": "WYX2158",
    "vesselType": 60,
    "vesselTypeName": "Passenger",
    "flag": "US",
    "flagName": "United States",
    "length": 27,
    "width": 9,
    "draught": 3.2,
    "deadweight": null,
    "grossTonnage": 96,
    "yearBuilt": 1978,
    "lastSeen": "2026-08-03T09:12:44.000Z"
  }
}

GET/api/v1/vessels/:mmsi/position

Latest position

Latest known position for a vessel, preferring the live AIS feed over stored data. The 'source' field indicates which was used.

Scope: vesselsCredits: 1Errors: INVALID_MMSIPOSITION_NOT_FOUND

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/position" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "mmsi": "366999712",
    "latitude": 37.802,
    "longitude": -122.405,
    "sog": 0.1,
    "cog": 233,
    "heading": 234,
    "navStatus": 5,
    "timestamp": "2026-08-03T09:14:02.000Z",
    "source": "live"
  }
}

GET/api/v1/vessels/:mmsi/voyage

Current voyage

Current voyage data for a vessel: reported destination, ETA, draught, and navigation status.

Scope: vesselsCredits: 1Errors: INVALID_MMSIVESSEL_NOT_FOUND

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/voyage" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "mmsi": "244660123",
    "destination": "NLRTM",
    "eta": "2026-08-04T18:00:00.000Z",
    "draught": 11.2,
    "navStatus": 0,
    "atd": "2026-07-30T04:12:00.000Z",
    "updatedAt": "2026-08-03T09:12:44.000Z"
  }
}

GET/api/v1/vessels/:mmsi/track

Historical track

Historical track points for a vessel. Defaults to the last 24 hours; the requested range may not exceed 31 days.

Scope: vesselsCredits: 3Errors: INVALID_MMSIINVALID_DATE_RANGERANGE_TOO_LARGE

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.
from	query	string (ISO-8601)	no	Range start (default: 24 hours ago).
to	query	string (ISO-8601)	no	Range end (default: now). Must be after 'from'; max span 31 days.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/track?from=2026-08-01T00%3A00%3A00Z&to=2026-08-03T00%3A00%3A00Z" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "latitude": 51.94,
      "longitude": 3.98,
      "sog": 13.1,
      "cog": 268,
      "heading": 269,
      "timestamp": "2026-08-02T23:55:00.000Z"
    }
  ],
  "meta": {
    "mmsi": "244660123",
    "from": "2026-08-01T00:00:00.000Z",
    "to": "2026-08-03T00:00:00.000Z",
    "count": 1
  }
}

GET/api/v1/vessels/:mmsi/photo

Vessel photo

Photo for a vessel. Imagery coverage is being rolled out; vessels without imagery return PHOTO_NOT_AVAILABLE.

Scope: vesselsCredits: 1Errors: INVALID_MMSIVESSEL_NOT_FOUNDPHOTO_NOT_AVAILABLE

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/photo" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "error": "No photo is available for this vessel",
  "code": "PHOTO_NOT_AVAILABLE"
}

GET/api/v1/vessels/:mmsi/risk

Risk assessment

AI-generated compliance/risk assessment for a vessel based on its registry profile. Results are cached for 6 hours.

Scope: vesselsCredits: 5Errors: INVALID_MMSIVESSEL_NOT_FOUND

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/risk" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "riskLevel": "low",
    "score": 12,
    "factors": [
      "Flag state has strong port-state-control record",
      "Vessel age within normal range"
    ],
    "summary": "No elevated risk indicators identified."
  },
  "meta": {
    "mmsi": "244660123",
    "generatedAt": "2026-08-03T09:20:11.000Z"
  }
}

GET/api/v1/vessels/:mmsi/position/satellite

Satellite position estimate

Position estimate for vessels outside terrestrial AIS coverage (open ocean). When the last terrestrial fix is recent, that authoritative position is returned with source 'terrestrial'; when it is stale, an extrapolated estimate is returned with source 'satellite'. Cached for 10 minutes.

Scope: vesselsCredits: 5Errors: INVALID_MMSISATELLITE_NOT_AVAILABLE

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/position/satellite" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "mmsi": "244660123",
    "imo": "9356803",
    "name": "MAERSK DETROIT",
    "latitude": 38.42,
    "longitude": -41.87,
    "sog": 16.2,
    "cog": 265,
    "heading": 266,
    "timestamp": "2026-08-08T07:55:00.000Z",
    "source": "satellite"
  }
}

GET/api/v1/vessels/:mmsi/port-calls

Port call history

Recorded port calls for a vessel — port, arrival, departure, and dwell time — derived from observed vessel movements, most recent first.

Scope: vesselsCredits: 2Errors: INVALID_MMSI

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.
limit	query	integer	no	Page size, 1–100 (default 50).
offset	query	integer	no	Rows to skip for pagination (default 0).

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/port-calls" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "portId": "NLRTM",
      "portName": "Rotterdam",
      "arrivalTime": "2026-08-01T06:20:00.000Z",
      "departureTime": "2026-08-02T14:05:00.000Z",
      "dwellMinutes": 1905,
      "purpose": "Cargo operations",
      "berthNumber": "E4"
    }
  ],
  "meta": {
    "mmsi": "244660123",
    "limit": 50,
    "offset": 0,
    "count": 1
  }
}

GET/api/v1/vessels/:mmsi/nearby

Vessels nearby

Live vessels currently around a given vessel — useful for spotting escorts, bunkering barges, tugs, or close-quarters traffic.

Scope: vesselsCredits: 2Errors: INVALID_MMSIPOSITION_NOT_FOUNDINVALID_RADIUS

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.
radius_nm	query	number	no	Search radius in nautical miles, 1–50 (default 10).
limit	query	integer	no	Max vessels returned, 1–100 (default 50).

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/nearby?radius_nm=10" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "mmsi": "215678000",
      "name": "FAIRPLAY 31",
      "imo": "9506253",
      "vesselTypeName": "Tug",
      "flag": "MT",
      "latitude": 51.952,
      "longitude": 4.081,
      "sog": 3.1,
      "cog": 92,
      "navStatus": 0,
      "destination": "NLRTM"
    }
  ],
  "meta": {
    "mmsi": "244660123",
    "radiusNm": 10,
    "count": 1
  }
}

GET/api/v1/vessels/:mmsi/encounters

Ship-to-ship encounters

Detected ship-to-ship (STS) encounters for a vessel — prolonged close-quarters meetings at sea, a key signal for transshipment monitoring. Computed continuously from observed vessel movements.

Scope: vesselsCredits: 3Errors: INVALID_MMSI

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.
days	query	integer	no	Look-back window in days, 1–365 (default 90).
limit	query	integer	no	Max encounters returned, 1–100 (default 20).

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/encounters" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "id": "b1f7…",
      "partnerMmsi": "215678000",
      "partnerName": "OCEAN TRADER",
      "partnerType": "Tanker",
      "startTime": "2026-07-21T02:10:00.000Z",
      "endTime": "2026-07-21T05:40:00.000Z",
      "durationMinutes": 210,
      "latitude": 35.92,
      "longitude": 14.38,
      "sampleCount": 14
    }
  ],
  "meta": {
    "mmsi": "244660123",
    "days": 90,
    "lastScanAt": "2026-08-08T06:00:00.000Z",
    "count": 1
  }
}

GET/api/v1/vessels/:mmsi/emissions

CO₂ emissions (EU MRV)

Verified annual CO₂ emissions and fuel consumption reported under the EU MRV scheme, one record per reporting year. Meta 'source' indicates whether records came from the local EU MRV dataset or a provider fallback.

Scope: vesselsCredits: 3Errors: INVALID_MMSI

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/emissions" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "imo": "9356803",
      "name": "MAERSK DETROIT",
      "reporting_period": "2025",
      "vessel_type": "Container ship",
      "co2_emissions_total": 48123.5,
      "co2_emissions_at_berth": 1830.2,
      "fuel_consumption_total": 15321.7,
      "total_time_at_sea": 5840,
      "verified": true
    }
  ],
  "meta": {
    "mmsi": "244660123",
    "imo": "9356803",
    "count": 1,
    "source": "eu-mrv",
    "providerUnavailable": false
  }
}

GET/api/v1/vessels/:mmsi/zones

Emission-zone status

Whether the vessel is currently inside an Emission Control Area (ECA/SECA), with the zone's sulfur limit and NOx Tier III status.

Scope: vesselsCredits: 1Errors: INVALID_MMSIPOSITION_NOT_FOUND

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/zones" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "mmsi": "244660123",
    "position": {
      "latitude": 51.95,
      "longitude": 4.08,
      "timestamp": "2026-08-08T08:01:00.000Z"
    },
    "inEmissionControlArea": true,
    "zone": {
      "id": "north-sea",
      "name": "North Sea ECA",
      "shortName": "North Sea",
      "sulfurLimit": "0.10% m/m",
      "noxTierIII": true,
      "effectiveFrom": "2021-01-01"
    }
  }
}

GET/api/v1/vessels/:mmsi/safety

Safety record (PSC)

Port State Control record across four regimes — Paris MoU (bans and detentions), Tokyo MoU, Black Sea MoU, and Riyadh MoU — plus the vessel's flag performance rating. Overall status is 'banned', 'detained', or 'clear'.

Scope: vesselsCredits: 4Errors: INVALID_MMSIVESSEL_NOT_FOUNDSAFETY_NOT_AVAILABLE

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/safety" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "mmsi": "244660123",
    "imo": "9356803",
    "name": "MAERSK DETROIT",
    "status": "clear",
    "parisMou": {
      "banned": [],
      "detained": [],
      "lastImportedAt": "2026-08-07T03:00:00.000Z"
    },
    "tokyoMou": {
      "detained": [],
      "lastImportedAt": "2026-08-07T03:10:00.000Z"
    },
    "blackSeaMou": {
      "detained": [],
      "lastImportedAt": "2026-08-07T03:12:00.000Z"
    },
    "riyadhMou": {
      "detained": [],
      "lastImportedAt": "2026-08-07T03:15:00.000Z"
    },
    "flagRating": {
      "code": "NL",
      "name": "Netherlands",
      "category": "white",
      "rank": 4,
      "listYear": 2025,
      "validFrom": "2025-07-01"
    }
  }
}

GET/api/v1/vessels/:mmsi/flag-risk

Flag performance rating

The vessel's flag state performance on the Paris MoU White/Grey/Black list — a quick screen for flags with poor inspection records.

Scope: vesselsCredits: 1Errors: INVALID_MMSIVESSEL_NOT_FOUNDFLAG_RATING_NOT_FOUND

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/flag-risk" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "mmsi": "244660123",
    "flag": "NL",
    "flagName": "Netherlands",
    "rating": {
      "code": "NL",
      "name": "Netherlands",
      "category": "white",
      "rank": 4,
      "listYear": 2025,
      "validFrom": "2025-07-01"
    }
  }
}

GET/api/v1/vessels/:mmsi/registry

Registry, ownership & due diligence

Ownership and management (beneficial owner, registered owner, operator, technical and commercial managers with country), classification society, main engine, build details, sales & demolition records, dry-dock and survey dates, inspection/detention history and marine casualties. Company names are screened against the sanctions lists. Meta 'sections' gives each section's status: 'ok', 'unavailable' (not included in the data subscription), 'error' (temporary), or for casualties 'partial' (not every casualty source could be checked — an empty list then does not mean no casualties).

Scope: vesselsCredits: 5Errors: INVALID_MMSIVESSEL_NOT_FOUNDREGISTRY_NOT_AVAILABLE

Parameter	In	Type	Required	Description
mmsi	path	string	yes	9-digit MMSI of the vessel.

Example request

curl "https://navtrac.io/api/v1/vessels/366999712/registry" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "mmsi": "636015321",
    "imo": "9575149",
    "vesselName": "DARYA MAYA",
    "companies": [
      {
        "role": "beneficial_owner",
        "name": "Dry Bulk Services",
        "country": "Hong Kong",
        "companyImo": "1796681",
        "fleetLookup": true
      },
      {
        "role": "technical_manager",
        "name": "Anglo-Eastern Management (HK)",
        "country": "Hong Kong",
        "companyImo": "0522961",
        "fleetLookup": true
      }
    ],
    "build": {
      "yearBuilt": 2012,
      "builder": null,
      "flag": "Liberia",
      "vesselType": "Bulk",
      "homePort": null,
      "operatingStatus": null,
      "piClub": null,
      "formerNames": []
    },
    "classification": {
      "society": "BV",
      "specialSurveyDate": "2027-03-01",
      "dryDockDate": "2025-02-14",
      "grossTonnage": 36330,
      "netTonnage": 21557,
      "deadweight": 63301,
      "lengthOverall": 199.9,
      "beam": 32.24,
      "depth": 18.5,
      "draft": 13.3,
      "propulsion": "Oil engine(s), direct drive"
    },
    "engine": {
      "designation": "6S50ME-C8.2",
      "builder": "Doosan Engine",
      "designer": "MAN B&W",
      "power": 8050,
      "powerUnit": "kW",
      "rpm": 117,
      "propulsion": "Oil engine(s), direct drive"
    },
    "salesDemolitions": [],
    "dryDock": {
      "lastDryDock": "2025-02-14",
      "specialSurvey": "2027-03-01",
      "ioppIssued": null,
      "ioppExpires": null
    },
    "inspections": [
      {
        "date": "2025-09-12",
        "authority": "Tokyo MoU",
        "port": "Kaohsiung",
        "type": "Initial inspection",
        "detained": false,
        "deficiencies": 2,
        "description": null
      }
    ],
    "casualties": [],
    "sanctions": {
      "screened": true,
      "matches": []
    }
  },
  "meta": {
    "imo": "9575149",
    "sections": {
      "ownership": "ok",
      "registry": "ok",
      "classification": "ok",
      "engine": "ok",
      "salesDemolitions": "ok",
      "dryDock": "ok",
      "inspections": "ok",
      "casualties": "ok"
    },
    "available": true,
    "fetchedAt": "2026-10-25T09:00:00.000Z",
    "ageSeconds": 120
  }
}

GET/api/v1/companies/fleet

Company fleet

Vessels a company controls in a given role. Use the role, name and companyImo values from a vessel's registry 'companies' entry; companyImo gives an exact match.

Scope: vesselsCredits: 3Errors: INVALID_ROLEINVALID_QUERY

Parameter	In	Type	Required	Description
role	query	string	yes	beneficial_owner, operator, technical_manager or commercial_manager
name	query	string	yes	Company name
companyImo	query	string	no	Company registration number (exact match)

Example request

curl "https://navtrac.io/api/v1/companies/fleet?role=operator&name=KC%20Maritime%20Hong%20Kong" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "imo": "9575149",
      "name": "DARYA MAYA",
      "flag": "Liberia",
      "vesselType": "Bulk",
      "yearBuilt": 2012,
      "deadweight": 63301
    }
  ],
  "meta": {
    "role": "operator",
    "name": "KC Maritime Hong Kong",
    "count": 1,
    "available": true,
    "status": "ok",
    "fetchedAt": "2026-10-25T09:00:00.000Z"
  }
}

Portsscope: ports

Port registry lookups, terminals, live traffic, expected arrivals, recorded departures, statistics, and port events.

GET/api/v1/ports

List / search ports

List ports, optionally filtered by free-text query and/or country.

Scope: portsCredits: 1

Parameter	In	Type	Required	Description
q	query	string	no	Free-text filter on port name, country, or UN/LOCODE.
country	query	string	no	Country code or name filter.
limit	query	integer	no	Page size, 1–200 (default 50).
offset	query	integer	no	Rows to skip for pagination (default 0).

Example request

curl "https://navtrac.io/api/v1/ports?q=rotterdam" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "id": "NLRTM",
      "uuid": "b8b1a1f0-0000-0000-0000-000000000000",
      "name": "Rotterdam",
      "unlocode": "NLRTM",
      "country": "Netherlands",
      "countryCode": "NL",
      "latitude": 51.95,
      "longitude": 4.14,
      "type": "Seaport",
      "size": "L"
    }
  ],
  "meta": {
    "limit": 50,
    "offset": 0,
    "total": 1,
    "count": 1
  }
}

GET/api/v1/ports/:id

Port details

Details for a single port by internal id, UN/LOCODE, or provider UUID.

Scope: portsCredits: 1Errors: PORT_NOT_FOUND

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "id": "NLRTM",
    "uuid": "b8b1a1f0-0000-0000-0000-000000000000",
    "name": "Rotterdam",
    "unlocode": "NLRTM",
    "country": "Netherlands",
    "countryCode": "NL",
    "latitude": 51.95,
    "longitude": 4.14,
    "type": "Seaport",
    "size": "L"
  }
}

GET/api/v1/ports/:id/terminals

Port terminals

Terminals within a port: terminal code and name, operating company, coordinates, website and address. Ports without terminal coverage return an empty list.

Scope: portsCredits: 2Errors: PORT_NOT_FOUND

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/terminals" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "code": "EMX",
      "name": "ECT EUROMAX TERMINAL (EMX)",
      "operator": "HUTCHISON PORTS ECT ROTTERDAM",
      "latitude": 51.974167,
      "longitude": 4.038056,
      "website": "https://www.ect.nl/",
      "address": "Maasvlakteweg 951, 3199 LZ Rotterdam (Maasvlakte), The Netherlands"
    }
  ],
  "meta": {
    "portId": "NLRTM",
    "count": 1
  }
}

GET/api/v1/ports/:id/vessels

Vessels in port

Live vessels currently in or near the port, within an adjustable radius.

Scope: portsCredits: 3Errors: PORT_NOT_FOUND

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.
radius_nm	query	number	no	Search radius in nautical miles, 1–50 (default 10).

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/vessels?radius_nm=10" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "mmsi": "244660123",
      "name": "MAERSK DETROIT",
      "vesselTypeName": "Cargo",
      "flag": "NL",
      "latitude": 51.951,
      "longitude": 4.083,
      "sog": 0.2,
      "navStatus": 5,
      "destination": "NLRTM"
    }
  ],
  "meta": {
    "portId": "NLRTM",
    "radiusNm": 10,
    "count": 1
  }
}

GET/api/v1/ports/:id/arrivals

Expected arrivals

Vessels reporting this port as their destination with an ETA inside the requested window.

Scope: portsCredits: 2Errors: PORT_NOT_FOUND

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.
window	query	string	no	Look-ahead window: 24h, 3d, or 7d (default 3d).

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/arrivals?window=3d" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "mmsi": "244660123",
      "name": "MAERSK DETROIT",
      "imo": "9356803",
      "vesselTypeName": "Cargo",
      "flag": "NL",
      "destination": "NLRTM",
      "eta": "2026-08-04T18:00:00.000Z",
      "sog": 12.4,
      "latitude": 51.4,
      "longitude": 2.9,
      "navStatus": 0,
      "lastSeen": "2026-08-03T09:12:44.000Z"
    }
  ],
  "meta": {
    "portId": "NLRTM",
    "window": "3d",
    "count": 1
  }
}

GET/api/v1/ports/:id/departures

Recorded departures

Recorded port calls with a departure time, most recent first.

Scope: portsCredits: 2Errors: PORT_NOT_FOUND

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.
limit	query	integer	no	Page size, 1–100 (default 50).
offset	query	integer	no	Rows to skip for pagination (default 0).

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/departures" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "mmsi": "244660123",
      "portName": "Rotterdam",
      "arrivalTime": "2026-08-01T06:20:00.000Z",
      "departureTime": "2026-08-02T14:05:00.000Z",
      "dwellMinutes": 1905,
      "purpose": "Cargo operations",
      "berthNumber": "E4"
    }
  ],
  "meta": {
    "portId": "NLRTM",
    "limit": 50,
    "offset": 0,
    "count": 1
  }
}

GET/api/v1/ports/:id/statistics

Port statistics

Traffic statistics for a port over the requested period. Cached for 15 minutes.

Scope: portsCredits: 2Errors: PORT_NOT_FOUND

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.
period	query	string	no	Aggregation period: day, week, or month (default month).

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/statistics?period=month" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "vesselsInPort": 143,
    "vesselsUnderway": 38,
    "vesselsAtBerthOrAnchor": 105,
    "expectedArrivals72h": 61,
    "byType": {
      "Cargo": 71,
      "Tanker": 34,
      "Tug": 18
    }
  },
  "meta": {
    "portId": "NLRTM",
    "period": "month"
  }
}

GET/api/v1/ports/:id/events

Port events

Recent arrival/departure events for a port. Requires a port with a UN/LOCODE. Cached for 10 minutes.

Scope: portsCredits: 2Errors: PORT_NOT_FOUNDEVENTS_NOT_AVAILABLE

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.
limit	query	integer	no	Max events, 1–50 (default 50).

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/events" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "eventType": "arrival",
      "mmsi": "244660123",
      "vesselName": "MAERSK DETROIT",
      "timestamp": "2026-08-03T05:41:00.000Z"
    }
  ],
  "meta": {
    "portId": "NLRTM",
    "count": 1
  }
}

GET/api/v1/ports/:id/facts

Port facts

Practical port characteristics from the World Port Index: harbor type and size, channel/anchorage/cargo-pier depths, pilotage and tug availability, supplies, repairs, cranes, and cargo facilities. Cached for 6 hours.

Scope: portsCredits: 2Errors: PORT_NOT_FOUNDFACTS_NOT_AVAILABLE

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/facts" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "wpiPortNumber": 31170,
    "portName": "ROTTERDAM",
    "countryCode": "NL",
    "countryName": "Netherlands",
    "unlocode": "NLRTM",
    "latitude": 51.9,
    "longitude": 4.48,
    "harborSize": {
      "code": "L",
      "label": "Large"
    },
    "harborType": {
      "code": "CN",
      "label": "Coastal natural"
    },
    "shelter": {
      "code": "G",
      "label": "Good"
    },
    "depths": {
      "channelM": 23.2,
      "anchorageM": 21.6,
      "cargoPierM": 18.9,
      "oilTerminalM": 22.9
    },
    "tideRangeM": 1.8,
    "maxVessel": {
      "lengthM": 366,
      "beamM": 49,
      "draftM": 21.3
    },
    "entry": {
      "goodHoldingGround": true,
      "turningArea": true,
      "firstPortOfEntry": true
    },
    "pilotage": {
      "compulsory": true,
      "available": true,
      "advisable": true
    },
    "tugs": {
      "assist": true,
      "salvage": true
    },
    "services": {
      "provisions": true,
      "freshWater": true,
      "fuelOil": true,
      "diesel": true,
      "medical": true,
      "garbage": true,
      "repairs": {
        "code": "A",
        "label": "Major"
      },
      "drydock": {
        "code": "L",
        "label": "Large"
      },
      "railway": {
        "code": "M",
        "label": "Medium"
      }
    },
    "cranes": {
      "fixed": true,
      "mobile": true,
      "floating": true
    },
    "facilities": {
      "wharves": true,
      "anchorage": true,
      "medMoor": false,
      "container": true,
      "roro": true,
      "solidBulk": true,
      "liquidBulk": true,
      "breakBulk": true,
      "oilTerminal": true,
      "dangerousCargo": true
    }
  },
  "meta": {
    "portId": "NLRTM",
    "source": "World Port Index"
  }
}

GET/api/v1/ports/:id/tides

Tide predictions

High/low tide predictions from the nearest NOAA station. Currently available for US ports with a NOAA station nearby; other ports return TIDES_NOT_AVAILABLE.

Scope: portsCredits: 2Errors: PORT_NOT_FOUNDTIDES_NOT_AVAILABLE

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/tides" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "stationId": "9414290",
    "stationName": "San Francisco",
    "stationDistanceKm": 3.2,
    "datum": "MLLW",
    "units": "m",
    "days": [
      {
        "date": "2026-08-08",
        "events": [
          {
            "time": "2026-08-08 04:12",
            "type": "H",
            "heightM": 1.71
          },
          {
            "time": "2026-08-08 10:47",
            "type": "L",
            "heightM": 0.28
          }
        ]
      }
    ]
  },
  "meta": {
    "portId": "USSFO",
    "source": "NOAA CO-OPS"
  }
}

GET/api/v1/ports/:id/weather

Port weather

Current marine weather conditions at the port's coordinates — a convenience wrapper so you don't have to look up the port position first.

Scope: portsCredits: 1Errors: PORT_NOT_FOUNDWEATHER_NOT_AVAILABLE

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/weather" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "current": {
      "waveHeight": 1.1,
      "wavePeriod": 5.4,
      "waveDirection": 245,
      "windWaveHeight": 0.6,
      "swellHeight": 0.7,
      "swellDirection": 250,
      "swellPeriod": 7.1,
      "oceanCurrentVelocity": 0.4,
      "oceanCurrentDirection": 12,
      "windSpeed": 14.2,
      "windDirection": 240,
      "temperature": 18.3,
      "weatherCode": 2,
      "visibility": 9600,
      "precipitation": 0,
      "seaState": "Slight",
      "seaStateLevel": 3,
      "beaufortScale": 4,
      "beaufortDescription": "Moderate breeze"
    },
    "hourly": [
      {
        "time": "2026-08-08T09:00",
        "waveHeight": 1.2,
        "waveDirection": 246,
        "windWaveHeight": 0.6,
        "swellHeight": 0.7,
        "windSpeed": 15.1,
        "windDirection": 242,
        "temperature": 18.6,
        "weatherCode": 2,
        "precipitation": 0
      }
    ],
    "daily": [
      {
        "date": "2026-08-08",
        "maxWaveHeight": 1.6,
        "maxWindSpeed": 19.4,
        "avgTemperature": 18.1,
        "dominantWeatherCode": 3
      }
    ],
    "attribution": "Marine weather from public forecast data",
    "tier": "free",
    "latitude": 51.95,
    "longitude": 4.14
  },
  "meta": {
    "portId": "NLRTM"
  }
}

GET/api/v1/ports/:id/congestion

Port congestion

Live congestion snapshot for a port: vessels nearby, how many are waiting at anchor or moored versus underway, the waiting ratio, and a congestion score where port-call history is available. Cached for 15 minutes.

Scope: portsCredits: 2Errors: PORT_NOT_FOUNDCONGESTION_NOT_AVAILABLE

Parameter	In	Type	Required	Description
id	path	string	yes	Port identifier: internal id, UN/LOCODE (e.g. NLRTM), or provider UUID.

Example request

curl "https://navtrac.io/api/v1/ports/NLRTM/congestion" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "vesselsNearby": 187,
    "waitingOrMoored": 141,
    "underway": 46,
    "waitingRatio": 0.75,
    "congestionScore": 68,
    "radiusNm": 15
  },
  "meta": {
    "portId": "NLRTM",
    "computedAt": "2026-08-08T08:05:00.000Z"
  }
}

Weatherscope: weather

Marine weather at a point and along a planned route.

GET/api/v1/weather/marine

Marine weather

Current marine weather conditions at a coordinate.

Scope: weatherCredits: 1Errors: INVALID_COORDINATES

Parameter	In	Type	Required	Description
lat	query	number	yes	Latitude (-90 to 90).
lon	query	number	yes	Longitude (-180 to 180).

Example request

curl "https://navtrac.io/api/v1/weather/marine?lat=51.95&lon=4.14" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "current": {
      "waveHeight": 1.1,
      "wavePeriod": 5.4,
      "waveDirection": 245,
      "windWaveHeight": 0.6,
      "swellHeight": 0.7,
      "swellDirection": 250,
      "swellPeriod": 7.1,
      "oceanCurrentVelocity": 0.4,
      "oceanCurrentDirection": 12,
      "windSpeed": 14.2,
      "windDirection": 240,
      "temperature": 18.3,
      "weatherCode": 2,
      "visibility": 9600,
      "precipitation": 0,
      "seaState": "Slight",
      "seaStateLevel": 3,
      "beaufortScale": 4,
      "beaufortDescription": "Moderate breeze"
    },
    "hourly": [
      {
        "time": "2026-08-08T09:00",
        "waveHeight": 1.2,
        "waveDirection": 246,
        "windWaveHeight": 0.6,
        "swellHeight": 0.7,
        "windSpeed": 15.1,
        "windDirection": 242,
        "temperature": 18.6,
        "weatherCode": 2,
        "precipitation": 0
      }
    ],
    "daily": [
      {
        "date": "2026-08-08",
        "maxWaveHeight": 1.6,
        "maxWindSpeed": 19.4,
        "avgTemperature": 18.1,
        "dominantWeatherCode": 3
      }
    ],
    "attribution": "Marine weather from public forecast data",
    "tier": "free",
    "latitude": 51.95,
    "longitude": 4.14
  }
}

POST/api/v1/weather/route

Route weather

Weather along a route of up to 20 waypoints. Each waypoint needs numeric lat/lon and may include an ISO-8601 estimatedTime for time-aware forecasts.

Scope: weatherCredits: 2Errors: INVALID_BODYTOO_MANY_WAYPOINTSINVALID_WAYPOINT

Parameter	In	Type	Required	Description
waypoints	body	object[]	yes	Array of { lat, lon, estimatedTime? } waypoints (max 20).

Example request

curl "https://navtrac.io/api/v1/weather/route" \
  -H "X-API-Key: YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -X POST -d '{"waypoints":[{"lat":51.95,"lon":4.14},{"lat":50.9,"lon":1.4,"estimatedTime":"2026-08-04T06:00:00Z"}]}'

Example response

{
  "data": {
    "points": [
      {
        "latitude": 51.95,
        "longitude": 4.14,
        "weather": {
          "waveHeight": 1.1,
          "wavePeriod": 5.4,
          "waveDirection": 245,
          "windWaveHeight": 0.6,
          "swellHeight": 0.7,
          "swellDirection": 250,
          "swellPeriod": 7.1,
          "oceanCurrentVelocity": 0.4,
          "oceanCurrentDirection": 12,
          "windSpeed": 14.2,
          "windDirection": 240,
          "temperature": 18.3,
          "weatherCode": 2,
          "visibility": 9600,
          "precipitation": 0,
          "seaState": "Slight",
          "seaStateLevel": 3,
          "beaufortScale": 4,
          "beaufortDescription": "Moderate breeze"
        },
        "delayHours": 0
      },
      {
        "latitude": 50.9,
        "longitude": 1.4,
        "weather": {
          "waveHeight": 1.8,
          "wavePeriod": 6.2,
          "waveDirection": 252,
          "windWaveHeight": 1,
          "swellHeight": 1.1,
          "swellDirection": 255,
          "swellPeriod": 7.8,
          "oceanCurrentVelocity": 0.6,
          "oceanCurrentDirection": 20,
          "windSpeed": 18.7,
          "windDirection": 248,
          "temperature": 17.4,
          "weatherCode": 61,
          "visibility": 7200,
          "precipitation": 0.4,
          "seaState": "Moderate",
          "seaStateLevel": 4,
          "beaufortScale": 5,
          "beaufortDescription": "Fresh breeze"
        },
        "delayHours": 0.5
      }
    ],
    "totalDelayHours": 0.5,
    "overallSeverity": "moderate"
  }
}

Compliancescope: compliance

Sanctions screening against published vessel sanctions lists.

GET/api/v1/sanctions/check

Sanctions check

Screen a vessel against sanctions lists by name, MMSI, or IMO. Provide at least one identifier; MMSI lookups are enriched with local registry data for better matching.

Scope: complianceCredits: 5Errors: INVALID_QUERY

Parameter	In	Type	Required	Description
name	query	string	no	Vessel name to screen.
mmsi	query	string	no	9-digit MMSI.
imo	query	string	no	7-digit IMO number.

Example request

curl "https://navtrac.io/api/v1/sanctions/check?name=OCEAN%20EXPLORER" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "query": {
      "mmsi": null,
      "imo": null,
      "name": "OCEAN EXPLORER"
    },
    "status": "clear",
    "matches": [],
    "sources": [
      "OFAC SDN",
      "EU Consolidated",
      "UK OFSI"
    ],
    "checkedAt": "2026-08-03T09:30:00.000Z"
  }
}

POST/api/v1/sanctions/check-batch

Batch sanctions screening

Screen up to 25 vessels against sanctions lists in one call — ideal for onboarding whole fleets. Each vessel needs at least one of name, MMSI, or IMO; entries with no usable identifier come back with status 'invalid'. Credits: 3 per vessel.

Scope: complianceCredits: 3 per vesselErrors: INVALID_BODYTOO_MANY_VESSELS

Parameter	In	Type	Required	Description
vessels	body	object[]	yes	Array of { mmsi?, imo?, name? } to screen (max 25).

Example request

curl "https://navtrac.io/api/v1/sanctions/check-batch" \
  -H "X-API-Key: YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -X POST -d '{"vessels":[{"mmsi":"366999712"},{"imo":"9811000"},{"name":"OCEAN EXPLORER"}]}'

Example response

{
  "data": [
    {
      "query": {
        "mmsi": "366999712",
        "imo": "7625354",
        "name": "GOLDEN GATE"
      },
      "status": "clear",
      "matches": []
    },
    {
      "query": {
        "mmsi": null,
        "imo": "9811000",
        "name": null
      },
      "status": "clear",
      "matches": []
    },
    {
      "query": {
        "mmsi": null,
        "imo": null,
        "name": "OCEAN EXPLORER"
      },
      "status": "match",
      "matches": [
        {
          "list": "OFAC SDN",
          "matchType": "name",
          "vessel": {
            "name": "OCEAN EXPLORER",
            "imo": "9038658",
            "aliases": [],
            "designatedDate": "2024-02-23"
          }
        }
      ]
    }
  ],
  "meta": {
    "requested": 3,
    "matched": 1,
    "sources": [
      "OFAC SDN",
      "EU Consolidated",
      "UK OFSI",
      "UN Consolidated"
    ],
    "checkedAt": "2026-08-08T08:10:00.000Z"
  }
}

Security & voyage planningscope: vessels

Piracy and maritime-security incident data, and port-to-port sea route calculation.

GET/api/v1/security/incidents

Security incidents

Piracy and maritime-security incidents reported by naval authorities. Call with no coordinates for the global feed, or pass lat/lon (and optional radius_nm) for incidents near a position.

Scope: vesselsCredits: 2Errors: INVALID_COORDINATESINVALID_RADIUS

Parameter	In	Type	Required	Description
lat	query	number	no	Centre latitude for a proximity search (use with lon).
lon	query	number	no	Centre longitude for a proximity search.
radius_nm	query	number	no	Proximity radius in nautical miles, 10–500 (default 200).
months	query	integer	no	Look-back window in months, 3–24 (default 12).
limit	query	integer	no	Page size, 1–500 (default 200).
offset	query	integer	no	Rows to skip for pagination (default 0).

Example request

curl "https://navtrac.io/api/v1/security/incidents?radius_nm=200" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "reference": "2026-145",
      "date": "2026-07-28",
      "latitude": 12.61,
      "longitude": 44.92,
      "category": "boarding",
      "hostility": "Pirates",
      "victim": "Bulk carrier",
      "navArea": "IX",
      "description": "Six persons in a skiff approached and boarded...",
      "source": "nga-asam"
    }
  ],
  "meta": {
    "count": 1,
    "radiusNm": 200,
    "months": 12,
    "latestIncidentAt": "2026-08-05"
  }
}

GET/api/v1/routes/sea

Sea route & distance

Shortest practical sea route between two coordinates: total distance in nautical miles plus the route line as GeoJSON-style [longitude, latitude] pairs. Routes between fixed points are cached for 6 hours.

Scope: vesselsCredits: 3Errors: INVALID_COORDINATESROUTE_NOT_FOUND

Parameter	In	Type	Required	Description
from_lat	query	number	yes	Origin latitude.
from_lon	query	number	yes	Origin longitude.
to_lat	query	number	yes	Destination latitude.
to_lon	query	number	yes	Destination longitude.

Example request

curl "https://navtrac.io/api/v1/routes/sea?from_lat=51.95&from_lon=4.05&to_lat=40.68&to_lon=-74.02" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "from": {
      "latitude": 51.95,
      "longitude": 4.05
    },
    "to": {
      "latitude": 40.68,
      "longitude": -74.02
    },
    "distanceNm": 3312.4,
    "coordinates": [
      [
        4.05,
        51.95
      ],
      [
        3.4,
        51.6
      ],
      [
        -74.02,
        40.68
      ]
    ]
  }
}

Reference & statusscope: any

Free lookups available to any valid API key — no scope required, zero credit cost.

GET/api/v1/reference/vessel-types

Vessel types

All vessel type codes and labels used across the API.

Scope: anyCredits: 0

Example request

curl "https://navtrac.io/api/v1/reference/vessel-types" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "code": 70,
      "label": "Cargo"
    },
    {
      "code": 80,
      "label": "Tanker"
    }
  ]
}

GET/api/v1/reference/flags

Flag states

All flag state codes and names used across the API.

Scope: anyCredits: 0

Example request

curl "https://navtrac.io/api/v1/reference/flags" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "code": "NL",
      "name": "Netherlands"
    },
    {
      "code": "PA",
      "name": "Panama"
    }
  ]
}

GET/api/v1/reference/ports

Port index

Lightweight index of known ports for id resolution.

Scope: anyCredits: 0

Parameter	In	Type	Required	Description
limit	query	integer	no	Page size, 1–500 (default 200).
offset	query	integer	no	Rows to skip (default 0).

Example request

curl "https://navtrac.io/api/v1/reference/ports" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": [
    {
      "id": "NLRTM",
      "name": "Rotterdam",
      "unlocode": "NLRTM",
      "country": "Netherlands"
    }
  ],
  "meta": {
    "limit": 200,
    "offset": 0,
    "total": 1,
    "count": 1
  }
}

GET/api/v1/account/usage

API usage & spend

Your key's request and credit usage over the requested period, broken down by endpoint. Free to call — use it to monitor spend programmatically.

Scope: anyCredits: 0

Parameter	In	Type	Required	Description
days	query	integer	no	Look-back window in days, 1–90 (default 30).

Example request

curl "https://navtrac.io/api/v1/account/usage" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "keyPrefix": "nvt_live_ab12",
    "periodDays": 30,
    "totalRequests": 1284,
    "totalCredits": 3711,
    "byEndpoint": [
      {
        "endpoint": "GET /vessels/{mmsi}/position",
        "requests": 840,
        "credits": 840
      },
      {
        "endpoint": "GET /sanctions/check",
        "requests": 61,
        "credits": 305
      }
    ]
  }
}

GET/api/v1/status

API status & account

API health plus your account status, remaining credits, key scopes, and rate limit. Free to call — useful as a connectivity check.

Scope: anyCredits: 0

Example request

curl "https://navtrac.io/api/v1/status" \
  -H "X-API-Key: YOUR_API_KEY"

Example response

{
  "data": {
    "status": "ok",
    "version": "v1",
    "timestamp": "2026-08-03T09:30:00.000Z",
    "account": {
      "name": "Acme Logistics",
      "status": "active",
      "creditsRemaining": 9421
    },
    "key": {
      "prefix": "nvt_live_ab12",
      "scopes": [
        "vessels",
        "ports"
      ],
      "rateLimitPerHour": 1000
    }
  }
}
